Equipment

MAJOR EQUIPMENT:



CNC Turning Centers

1 ea. Hitachi Seiki Hi-Tech-Turn 25G

Chuck Size: 10″ Dia.
Swing Over Bed: 24.8
Maximum Machining Length: 24″
Maximum Machining Diameter: 16.1″
Maximum Spindle Speed: 3,600 R.P.M.
CNC Controls: Seicos-LIII

1 ea. Hitachi Seiki Hi-Tech Turn 20J

Chuck Size: 8″
Swing over bed: 17.7″
Maximum Machining Length: 15.5″
Maximum Machining Diameter: 13.3″
Maximum Spindle Speed: 5,000 R.P.M.
CNC Controls: Seicos-J

1 ea. Mori Seiki SL-15 CNC Turning Center

Chuck Size: 6″ Dia.
Swing Over Bed: 17.7″
Maximum Machining Length: 20.7″
Maximum Machining Diameter: 6.3″
Maximum Spindle Speed 6,000 R.P.M.
CNC Controls: Fanuc 10-T

1 ea. Hardinge Talent 6/45-5V

Chuck Size: 6″ Dia.
Swing Over Bed: 12.”
Maximum Machining Length: 12.”
Max Machining Diameter: 6.0″
Maximum Spindle Speed 6,000 R.P.M.
CNC Controls; Fanuc

1 ea. Mori Seiki SL-15 CNC Turning Center

Chuck Size: 6″ Dia.
Swing Over Bed: 17.7″
Maximum Machining Length: 20.7″
Maximum Machining Diameter: 6.3″
Maximum Spindle Speed 6,000 R.P.M.
CNC Controls: Fanuc 10-T

1 ea. Mori Seiki SL-25 CNC Turning Center

Chuck Size: 8″ Dia.
Swing Over Bed: 20.5″
Maximum Machining Length: 21.7″
Maximum Machining Diameter: 10.2″
Maximum Spindle Speed 4,200 R.P.M
CNC Controls: Fanuc 0

1 ea Dainichi M95 CNC Turning Center

Chuck Size: 24″ Dia
Swing Over Bed: 37.5″
Maximum Machining Length: 59.0″
Maximum Machining Diameter: 37.5″
Maximum Spindle Speed 1,200 R.P.M.
CNC Controls: Fanuc 6-T

1 ea. Hitachi Seiki 4NE-600 CNC Turning Center

Chuck Size: 10″ Dia.
Swing Over Bed: 22.75″
Maximum Machining Length: 24″
Maximum Machining Diameter: 12″
Maximum Spindle Speed 3,150 R.P.M.
CNC Controls: Fanuc 5T

1 ea. Ikegai AZ25N CNC Turning Center

Chuck Size: 10″ Dia.
Swing Over Bed: 22.75″
Maximum Machining Length: 24″
Maximum Machining Diameter: 12″
Maximum Spindle Speed 3,600 R.P.M.
CNC Controls: Fanuc 6T

1 ea. Mori Seiki SL-15 CNC Turning Center

Chuck Size: 6″ Dia. .
Swing Over Bed: 17.7″
Maximum Machining Length: 20.7″
Maximum Machining Diameter: 6.3″
Maximum Spindle Speed: 6,000 R.P.M.
CNC Controls: Fanuc 10-T

1 ea. Kia Turn 25

Chuck Size: 10″ Dia.
Swing Over Bed: 24.8
Maximum Machining Length: 24″
Maximum Machining Diameter: 16.1″
Maximum Spindle Speed: 3,600 R.P.M.
CNC Controls: Fanuc

CNC Machining Centers

5 axis Mazak – 50 taper Smooth Technology

Max work piece size: (39.37 in dia X 19.69 in Ht)
Table size: (31.5 in dia X 24.8″ in Ht)
Max workpiece weight: (2205 IBS)
Spindle Note: 50 Taper
Spindle Speed: 10,000 RPM
Intergrated Two pallet changer
Controls: Smooth Control X 2

1 ea 5 Axis Mazak Variaxis i-800

Max work piece size: (39.37 in dia X 19.69 in Ht)
Table size: (31.5 in dia X 24.8″ in Ht)
Max workpiece weight: (2205 IBS)
Spindle Note: 50 Taper
Spindle Speed: 10,000 RPM
Intergrated Two pallet changer
Controls: Mazatrol Matrix 2

1 ea Okuma MB-4000H Horizontal 4th Axis

Table Size: X Axis: 22.05″
Y Axis: 22.05
Z axis: 25.00
Full B Axis
Tool Selection: 60 ea
Spindle Note: Plus 40
Spindle Speed: 50-15,000 RPM
Rapid Transverse: 60 (2,362) mm/m
Cutting federate: 60,000 (2,362)
Shuttle table
Controls: Okuma

1 ea Okuma MB-4000H Horizontal 4th Axis

Table Size: X Axis: 22.05″
Y Axis: 22.05
Z axis: 25.00
Full B Axis
Tool Selection: 60 ea
Spindle Note: Plus 40
Spindle Speed: 50-15,000 RPM
Rapid Transverse: 60 (2,362) mm/m
Cutting federate: 60,000 (2,362)
Shuttle table
Controls: Okuma

2 ea Hardinge Bridgeport’s GX 480 APC

Table Size: X Axis: 18.90″
Y Axis: 15.75″
Z Axis: 16.93″
Spindle Taper: No 40
Spindle Speed: 10,000 RPM
Tool Changer: 20 ea
Control: Fanuc I Series GX

1 ea. Dahlih 610 Vertical Machining Center

Table Size: X Axis: 24″
Y Axis: 18″
Z Axis: 20″
Tool Selection: 16 Ea.
Spindle Nose: CAT 40
Spindle Speed: 60-6,000 R.P.M.
Controls: Fanuc 10M

1ea. Hardinge/Bridgeport Vertical Machining Center

Table Size: X axis 20.”
Y axis 20.”
Z axis 12.”
Tool Selection; 20 ea.
Spindle Nose: CAT 40
Main Drive: 12 HP
Controls: Fanuc

1 ea. Okuma MC-4VAE

Table Size: X Axis: 30″
Y Axis: 16.14″
Z Axis: 17.72″
Tool Selection: 20 Ea.
Spindle Nose: CAT 40
Spindle Speed: 50-6,000 Cont. R.P.M.
Main Drive: Gear Drive 2 speed 20HP
Controls: Okuma OSP5020M

1 ea. Hitachi Seiki VM20II

Table Size: X Axis: 22″
Y Axis: 16″
Z Axis: 16″
Tool Selection: 20 Ea.
Spindle Nose: CAT 40
Spindle Speed: 60-8,000 R.P.M.
Main Drive: Direct 15HP
Controls: Seicos M III

1 ea. Haas VF-7 Vertical Machining Center

Table Size: X Axis: 84″
Y Axis: 32″
Z Axis: 30″
(4 th Axis x 15″ dia)
Tool Selection: 20 Ea.
Spindle Nose: CAT 40
Spindle Speed: 60-10,000 R.P.M.
Main Drive: 30HP
Controls: Haas

1 ea. Haas VF-7 Vertical Machining Center

Table Size: X Axis: 84″
Y Axis: 32″
Z Axis: 30″
(4 th Axis x 15″ dia)
Tool Selection: 20 Ea.
Spindle Nose: CAT 40
Spindle Speed: 60-10,000 R.P.M.
Main Drive: 30HP
Controls: Haas

1 ea. Haas VF-4 Vertical Machining Center

Table Size: X Axis: 50″
Y Axis: 20″
Z Axis: 25″
Tool Selection: 20 Ea.
Spindle Nose: CAT 40
Spindle Speed: 60-10,000 R.P.M.
Main Drive: 30HP
Controls: Haas

1 ea. Okuma MX-60 Machining Center

Table Size: X axis 37″
Y axis 37″
Z axis 37″
Tool Selection: 40 Ea.
Spindle Nose: CAT 50
Spindle Speed: 60-5,000 RPM
Main Drive: 30 HP
Controls: Okuma

1ea. Kia KV75 Vertical Machining Center

Table Size: X axis 61″
Y axis 29.5″
Z axis 27.6″
Tool Selection: 20 Ea.
Spindle Nose: NT# 50
Spindle Speed: 45-4,500
Main Drive: 20 HP
Controls: Fanuc 18M-C

1ea. Hardinge/Bridgeport Vertical Machining Center

Table Size: X axis 20.”
Y axis 20.”
Z axis 12.”
Tool Selection; 20 ea.
Spindle Nose: CAT 40
Main Drive: 12 HP
Controls: Fanuc

1 ea. Okuma MX-60 Machining Center

Table Size: X axis 37″
Y axis 37″
Z axis 37″
Tool Selection: 40 Ea.
Spindle Nose: CAT 50
Spindle Speed: 60-5,000 RPM
Main Drive: 30 HP
Controls: Okuma

Conventional Equipment

Lathes

4 ea. Hardinge HC Lathes
2 ea. No. 5 Warner & Swasey Lathes
1 ea. No. 1 Warner & Swasey Lathes
2 ea. No. 2 Warner & Swasey Lathes

Mills

1 ea. Bridgeport Vertical Mill
1 ea. Pilgrim Vertical Mill
1 ea. No. 2 K & T Horizontal Mill

Misc

1 ea. Sunnun Hone (Honing Machine)
1 ea. Hyd-Mech Horizontal Auto Saw
1 ea. Hydro Arbor Press
1 ea. Hydraulic Broaching Machine
